23. 906M Series

　

Post Bed Type, 1-Needle, Lock Stitch,

Fishing Rod Type Take-up, Lower Feed,

Zigzag Industrial Sewing Machine (Large Hook)

　

--		-
Lower Feed	Front	Back

　

1. SPECIFICATIONS :

MODEL	DESCRIPTION	MAX. BIGHT	PRESSER FOOT CLEARANCE (KNEE/HAND)	NEEDLE TYPE	CIRCUMFERENCE OF THE PSOT	MAX. SPEED (S.P.M.)
475A-906-M	plain zigzag	12.0 mm	12.0 mm	DPx17 #14 - #24	280 mm	2000 s.p.m.
475A-926-M	2-step 3-point zigzag	12.0 mm	12.0 mm	DPx17 #14 - #24	280 mm	2000 s.p.m.
475A-936-M	3-step 4-point zigzag	12.0 mm	12.0 mm	DPx17 #14 - #24	280 mm	2000 s.p.m.

-

2. FEATURES :

1.	Graduated dial for feed adjustment. Feed amount is adjustable easily by setting a suitable number on the graduated dial.
2.	Large hook. By adoption of large hook, the winding volume of lower thread is increased and due to this feature, the frequency of lower thread replacement is minimized.
3.	Convenient reverse feed lever. Reverse feed can be performed by finger soft touch of press-down lever with spring return.
4.	Semi-Automatic oil reservoir lubrication system.
5.	Suitable for sewing concave, convex, spheroidal, tubular, bowlike objects.
6.	Suitable for sewing small pieces, odd and small curved uneven shapes, with strong climbing capability and even stitch.
7.	Clearly arranged thread guide.
8.	Presser foot clearance (knee / hand) : 10 mm.
9.	Needle type : DPx17 #14-#22

　

　

Post Bed Type, 1-Needle, Lock Stitch,

Lower Feed, Heavy-Duty

Zigzag Industrial Sewing Machine (Large Hook)

23. 906M Series

　

　

　

　
